Inclined-Plane Tracking and Erosion Tester
As per IEC60587-2007, ASTM D2303
SENSORS INDIA LLP Inclined-Plane Tracking and Erosion TesterCore Technical Specifications
The IEC/EN 60587 apparatus typically includes the following components and settings:
- Test Methods: It supports both Method 1 (Constant Tracking Voltage) and Method 2 (Stepwise Tracking Voltage).
- Voltage Range: Usually adjustable from 100V to 6,000V AC (or up to 7,500V in some advanced models) with a stability of
- Specimen Orientation: Samples are mounted at an inclination of 45° 2° from the horizontal.
- Contaminant Delivery: A liquid contaminant (typically 0.1% Ammonium Chloride with a wetting agent) is fed at precise rates ranging from 0.075 ml/min to 0.900 ml/min, depending on the test voltage.
- Electrodes: Made of stainless steel (Grade 302), with the top and bottom electrodes spaced 50 mm apart.
- Safety Features: Includes an earthed safety enclosure, UV-protected glass doors, and overcurrent devices that trip if current exceeds 60 mA for 2–4 seconds
- Application: Cable Insulation, High voltage
