The DIELECTRIC HIGH VOLTAGE TEST

High Voltage Breakdown Testers are essential for evaluating the breakdown (flash-over) voltages of various electrical and electronic components. These testers are widely used for assessing the dielectric strength of motors, transformers, pumps, chokes, coils, switches, connectors, plastics, rubbers, PCBs, insulation materials, and other critical components.

Ideal for applications in industries, railways, electricity boards, defence, communication centres, R&D organizations, laboratories, colleges, and service centres, these testers ensure precise and reliable testing.

Key Features:

✅ Automatic Tripping Facility – Ensures operator safety by disconnecting high voltage during faults.
✅ HT ON/OFF Visual Indications – Clearly displays the operational status.
✅ HT ON Buzzer – Audible alert for high-voltage activation.
✅ High Voltage Safety Probe with Push Button Enable – Operator-controlled activation for added protection.
✅ Continuous Monitoring – HT voltage and leakage current meters provide real-time readings.
✅ Adjustable Tripping Current – Front panel control allows setting tripping levels from 0 to maximum.
✅ Digital Leakage Current Display – Displays actual leakage current during testing.

Safety Features:

⚡ Safe Power-On Sequence: High voltage remains OFF when mains supply is turned ON and is enabled only when the push button on the safety probe is actively pressed.
⚡ Multiple Safety Locks – Prevent accidental operation.
⚡ Built-in Operator Safety – Designed for secure and reliable use.

Technical Specifications:

🔹 Voltage Ratings: 0-3 KV, 5 KV, 10 KV, 20 KV, 50 KV, 100 KV
🔹 Custom Higher Ratings Available – Can be designed as per customer requirements.
